4" Low Mid Frequency Loudspeaker (APMB-4001ND-4)

• LOW MID-RANGE SERIES: The APMB-4001ND-4 features a cloth edge surround designed to enhance low-frequency performance. This innovative construction maximizes mid-range clarity while delivering rich, powerful low tones.
• POWDER-COATED BLACK STEEL BASKET: Built with a durable powder-coated black steel basket, the APMB-4001ND-4 provides exceptional strength and stability. This design helps isolate internal air from external frequencies, ensuring efficient operation with minimal interference, resulting in clean, precise sound reproduction.
• HIGH-QUALITY VOICE COIL: Equipped with a 1" high-temperature KSV voice coil, the APMB-4001ND-4 is engineered for superior heat dissipation and durability, enabling consistent, high-performance operation.
• HIGH-FREQUENCY ENHANCING BULLET: Designed with a high-frequency enhancing bullet, this loudspeaker extends its range into high frequencies without compromising low- to mid-range performance, delivering a well-balanced and dynamic audio output.
• EASY INSTALLATION: The APMB-4001ND-4 is designed with pre-drilled mounting holes for quick installation. Its compact size and mid-range frequency response make it ideal for a wide variety of applications, including use in limited-space enclosures.
• NEODYMIUM MAGNET: Features a powerful neodymium magnet for strong power handling and enhanced performance in a compact design.
• PEAK POWER: 100 Watts (P.M.P.O.)
• CONTINUOUS POWER: 50 Watts (R.M.S.)
• FREQUENCY RESPONSE: 100Hz – 15,000Hz
• SENSITIVITY: 89dB
• MOUNTING DEPTH: 45mm (1-3/4”)
• IMPEDANCE: 4 Ohms

Description:

The APMB-4001ND-4 is a high-performance 4" low mid-frequency loudspeaker engineered for maximum clarity and impact. Its powder-coated black steel basket ensures long-lasting durability while isolating internal air from external interference, resulting in exceptionally clean sound reproduction. Featuring a high-temperature KSV voice coil with optimized ventilation, this speaker delivers outstanding performance and reliability. Compact yet powerful, the APMB-4001ND-4 is the perfect upgrade for achieving balanced, high-quality mid-range sound in any audio system.

APMB-4001ND-4-English/Spanish Product Manual
